Image Sensor

1/2.7″ CMOS Sensor

Display Resolution

2304×1296 (3 Megapixels)

Lens

f=4.0mm Fixed, F=2.4, with IR Cut

Angle of View

• Horizontal: 82°

• Vertical: 43°

Pan/Tilt Angle

• Horizontal: 355°

• Vertical: 50°

Minimum Illumination

0 Lux (with IR Illuminator)

IR Distance

12m (40ft) (LED: 8pcs/14mil/850nm)

Dimension

Φ76x106mm

Weight

200g

Power Input

DC 5.0V/1A

Interface

• Power

• microSD Card Slot (Max. 512GB)

• Built-in Microphone and Speaker

• Reset Button

Protocols & Standards

SSL, TCP/IP, UDP, IPv4, UPnP, SMTP, NTP, DHCP, DNS, DDNS, P2P

Image Compression

H.264

Maximal Frame Rate

20fps

Code Rate

1024Kbps ~ 4096Kbps (default: 2560Kbps)

Audio

Two-Way Audio

Maximal User Access

20 Users (1 admin account & 19 user accounts); Support up to 4 simultaneous video streams (2 substreams & 2 mainstreams)

Browser Supported

No

Smart Alarm

Motion Detection/Person Detection/Pet Detection

OS Supported

PC: Windows, Mac OS; Smartphone: iOS, Android

Record Mode

Motion-Triggered Recording; Scheduled Recording; 24/7 Recording

Wireless Standard

IEEE 802.11 b/g/n

Operating Frequency

2.4 GHz

Wireless Security

WPA-PSK/WPA2-PSK
